| 序號 | 規格型號 | 額定流量 | 額定揚程 | 額定電壓 | 額定功率 | 配管內徑 |
| m³/h | m | V | KW | mm | ||
| 1 | WQ15-15-2.2N | 15 | 15 | 380/660 | 2.2 | 50 |
| 2 | WQ25-10-2.2N | 25 | 10 | 380/660 | 2.2 | 50 |
| 3 | WQ35-7-2.2N | 35 | 7 | 380/660 | 2.2 | 80 |
| 4 | WQ50-10-4N | 50 | 10 | 380/660 | 4 | 80 |
| 5 | WQ75-7-4N | 75 | 7 | 380/660 | 4 | 80 |
| 6 | WQ50-15-5.5N | 50 | 15 | 380/660 | 5.5 | 80 |
| 7 | WQ70-10-5.5N | 70 | 10 | 380/660 | 5.5 | 80 |
| 8 | WQ45-22-7.5N | 45 | 22 | 380/660 | 7.5 | 80 |
| 9 | WQ70-15-7.5N | 70 | 15 | 380/660 | 7.5 | 80 |
| 10 | WQ100-15-11N | 100 | 15 | 380/660 | 11 | 100 |
| 11 | WQ140-10-11N | 140 | 10 | 380/660 | 11 | 100 |
| 12 | WQ60-25-11N | 60 | 25 | 380/660 | 11 | 80 |
| 13 | WQ80-20-11N | 80 | 20 | 380/660 | 11 | 80 |
| 14 | WQ60-30-15N | 60 | 30 | 380/660 | 15 | 80 |
| 15 | WQ80-25-15N | 80 | 25 | 380/660 | 15 | 80 |
| 16 | WQ100-19-15N | 100 | 19 | 380/660 | 15 | 100 |
| 17 | WQ60-40-22N | 60 | 40 | 380/660 | 22 | 100 |
