公司基本資料信息
|
|||||||||||||||||||||||||
| 型號(hào) | 流量 L/h | 電機(jī)功率 kW | 柱塞直徑 mm | 行程 mm | 泵速 min-1 | 進(jìn)出口徑(d) mm | |
| 0.37 | 0.55 | ||||||
| 排出壓力 MPa | |||||||
| 3J-W 0.7/40(50) | 0.7 | 40 | 50 | 2 | 15 | 96 | 6 |
| 3J-W 1.5/32(50) | 1.5 | 32 | 50 | 3 | |||
| 3J-W 2.8/18(40) | 2.8 | 18 | 40 | 4 | |||
| 3J-W 4.6/10(32) | 4.6 | 10 | 32 | 5 | |||
| 3J-W 6.7/7.4(22) | 6.7 | 7.4 | 22 | 6 | |||
| 3J-W 12/4(12) | 12 | 4 | 12 | 8 | |||
| 3J-W 19/2.6(8) | 19 | 2.6 | 8 | 10 | |||
| 3J-W 28/1.8(5.3) | 28 | 1.8 | 5.3 | 12 | 8 | ||
| 3J-W 38/1.3(3.9) | 38 | 1.3 | 3.9 | 14 | |||
| 3J-W 50/1(3) | 50 | 1 | 3 | 16 | |||
| 3J-W 63/0.8(2.4) | 63 | 0.8 | 2.4 | 18 | |||
| 3J-W 78/0.65(1.9) | 79 | 0.65 | 1.9 | 20 | |||
|
|
|
|
|
|
|
|
點(diǎn)擊圖片查看原圖
